Set: Solar Frame
The Connect S2 Gateway can be integrated into the Solar Frame (with 2 solar cells) and together with this results in a solar-
powered self-sufficient tracking device. For this set you need the single device Connect S2 described above.
Order number: 0804.GV5.750
Quantity Product Picture
1 Solar Frame 2-cell
4 Washer DIN 522 stainless steel A2 blank 6.4 x 35 x 1.5 mm
4 Flange nuts self-locking DIN 6926 A2 M5
4 Plugs
Accessories: Mounting set 0 mm – 3 mm
The set is used to fix the Solar Frame on a carrier (gluing) or through a carrier with a thickness of up to 3 mm (screwing
through).
Order number: 3843.AY0.451
Quantity Product Picture
4 Gluing studs M5 x 15 mm
Accessories: Mounting set 4 mm – 13 mm
The set is used to fix the Solar Frame on a carrier (gluing) or through a carrier with a thickness of 4 mm up to 13 mm
(screwing through).
Order number: 3843.AY0.452
Quantity Product Picture
4 Gluing studs M5 x 25 mm
