Operation of the control unit
9
Control 8311/8313 – 6720859790 (2020/02)
Fig. 5 Operating and display elements
[1] Display of system, subsystem or function
[2] Status display of active menu level
[3] Display of temperature set (set temperature)
[4] Display of operating mode set
[5] Display of time program set
[6] Display of system components
[7] Advanced functions for heating circuit, DHW
[8] Display of time
[9] Field for switching between the display type (old/new display
version) on the display
[10] Information menu
[11] Field for returning to the previous level/screen
[12] Field for returning to the system overview
[13] Status display of system components
0010029513-001
12:00
50 °C
on/o
30 %
1 2 3 4 5
6
101112
13
7
8
9
