| 24 | KTS 560 / 590 (KTS 5a Series) | Decommissioning
6. Decommissioning
6.1 Temporary shutdown
In the event of lengthy periods of non-use:
6.2 Change of location
¶ If the KTS 560 / 590 (KTS 5a Series) is passed on, all
the documentation included in the scope of delivery
must be handed over together with the unit.
¶ The KTS 560 / 590 (KTS 5a Series) is only ever to be
transported in the original or equivalent packaging.
¶ Unplug the electrical connection.
¶ Heed the notes on initial commissioning.
6.3 Disposal and scrapping
1. Disconnect the KTS 560 / 590 (KTS 5a Series) from
the mains and detach the power cord.
2. Dismantle the KTS 560 / 590 (KTS 5a Series) and
sort out and dispose of the different materials in
accordance with the applicable regulations.
KTS 560 / 590 (KTS 5a Series), accessories
and packaging should be sorted for environ-
mental-friendly recycling.
¶ Do not dispose
KTS 560 / 590 (KTS 5a Series) into house-
hold waste.
Only for EC countries:
The KTS 560 / 590 (KTS 5a Series) is sub-
ject to the European directive 2012/19/EC
(WEEE).
Dispose of used electrical and electronic
devices, including cables, accessories and
batteries, separately from household waste.
¶ Make use of the local return and collection
systems for disposal.
¶ Proper disposal of
KTS 560 / 590 (KTS 5a Series) prevents
environmental pollution and possible health
hazards.
en
¶ Disconnect KTS 560 / 590 from the mains.
¶ If the device is sold to another party, the firmware
on KTS 560 / 590 (KTS 5a Series) must be deleted for
licensing reasons. To delete the firmware select "Firm-
ware update >> Restore default settings" in the DDC.
7. Technical Data
7.1 General data
Property Value/range
Operating voltage 8VDC — 28VDC
Power consumption via vehicle battery or
power supply unit
10watts
Dimensions with black
protective rubber corners (W x H x D)
130 x 45 x 185 mm
4.9 x 1.7 x 7.1 inch
Weight (without accessories) 0,5 kg
1.1 lb
Degree of protection
(with cap closed and OBD connecting ca-
ble attached)
IP 53
Operating temperature 5 °C - 40 °C
41 °F - 104 °F
Storage Temperature -25 °C - 60 °C
-13 °F - 140 °F
Relative humidity (non-condensing) 20 % - 80 %
7.2 Interface protocols
The following interfaces and their associated protocols
are supported for control unit diagnosis in compliance
with ISO 15031:
R ISO 22900
R SAE J2534-1 and -2 (PassThru)
R ISO 13400 (Diagnostic over IP)
R ISO 9141-2 (communication lines K and L)
R SAE J1850VPW and SAE J1850PWM
R (communication lines BUS+ and BUS-)
R CAN ISO 11898 ISO 15765-4 (OBD)
(communication lines CAN-H and CAN-L)
R CAN Single Wire
R CAN Low Speed
R and additional vehicle-specific special protocols
i KTS 560 / 590 (KTS 5a Series) may be used for Euro
5-compatible vehicles with the PassThru Standard.
7.3 Multimeter specifications
Measurement channel 1 (CH1) floating
Measurement channel 2 (CH2) floating
Input resistance > 900kohms.
7.3.1 DC measurement (CH1 and CH2)
! Use measurement cables for measurements smaller
than 60VDC, 30VAC or 42VACpeak only.
Property Value/range
Measuring range 200 mV — 60 V
Accuracy of CH1
and CH2
±0.75% of measured value
plus ±0.25% of measuring range
Resolution 100µV — 100mV
(depending on measuring range)
