44 | LV Heat Pump Series
LV Heat Pump Series8 733 944 336 (2016/09) Subject to change without prior notice
OPERATING DATA
COOLING HEATING
MODEL
ENTERING
WATER TEMP,
˚F
WATER FLOW
GPM
SUCTION
PRESSURE
PSIG
DISCHARGE
PRESSURE
PSIG
WATER TEMP
RISE, ˚F
AIR TEMP
DROP, ˚F
SUCTION
PRESSURE
PSIG
DISCHARGE
PRESSURE
PSIG
WATER
TEMP DROP,
˚F
AIR TEMP
RISE, ˚F
LV041
&
LV042
30˚
6 64-78 248-303 5-6 15-18
10 67-82 254-311 3-4 16-19
40˚
6 109-134 183-224 18-22 19-23 75-91 261-319 6-8 17-21
10 105-128 172-210 10-12 20-25 79-96 267-327 4-5 18-23
50˚
6 118-144 214-261 18-22 19-23 142-173 273-334 8-10 20-24
10 113-138 201-245 10-12 20-24 149-182 280-342 5-7 21-26
60˚
6 122-149 244-298 17-21 18-22 96-117 286-349 9-11 22-27
10 117-143 230-281 10-12 19-24 101-123 293-358 6-8 24-29
70˚
6 126-154 275-336 17-21 18-22 107-131 299-365 11-13 25-30
10 121-148 258-316 10-12 19-23 113-138 306-374 7-9 26-32
80˚
6 130-159 310-378 17-21 17-21 117-143 311-380 12-15 27-33
10 125-153 291-356 10-12 18-22 123-151 319-390 8-10 29-35
90˚
6 134-164 349-426 17-20 17-20 128-157 324-396 13-16 29-36
10 129-158 328-401 9-12 18-22 135-165 332-406 9-11 31-38
100˚
6 139-170 392-480 16-20 16-20
10 133-163 369-451 9-11 17-21
LV048
30˚
6 71-87 277-339 6-7 15-19
10 75-92 284-347 4-5 16-20
40˚
6 118-144 194-237 21-25 19-23 84-102 291-356 7-9 18-22
10 113-138 182-223 12-14 20-24 88-108 299-365 5-6 19-23
50˚
6 127-155 226-276 21-25 18-22 159-194 305-373 9-11 20-25
10 122-149 213-260 12-14 19-24 167-204 313-383 6-7 21-26
60˚
6 131-160 259-316 21-25 18-22 108-132 320-391 10-13 23-28
10 126-154 243-297 12-14 19-23 113-138 328-400 7-9 24-29
70˚
6 136-166 291-355 20-25 17-21 120-147 334-408 12-15 25-31
10 130-159 273-334 12-14 18-22 126-154 342-418 8-10 27-32
80˚
6 140-171 328-401 20-24 17-20 131-161 348-425 14-17 27-34
10 135-165 308-377 11-14 18-22 138-169 356-436 9-11 29-36
90˚
6 145-177 369-451 20-24 16-20 144-176 362-442 15-18 30-37
10 139-170 347-424 11-14 17-21 151-185 371-453 10-12 32-39
100˚
6 149-183 415-508 19-24 16-19
10 143-175 391-477 11-14 17-21
