Cable tree
Use the following table to identify the wires in the cable tree:
Wire color AWC Signal
Red 26 +12 VDC
Brown 26 -12 VDC
Yellow /
Green
24 Earth
Black /
Brown
28 Alarm Out A
White /
Orange
28 Alarm Out B
White /
Violet
28 Ground (Alarm In)
Orange /
Violet
28 Alarm In 1
Violet 28 Alarm In 2
White 28 Audio In
(Shield) 28 Ground (Audio)
Black 28 Audio Out
BNC
connector
CVBS analog
Earthing
!
Caution!
This device must be connected to earth (ground).
Safety (power) ground is indicated by the symbol.
5.3.1
5.3.2
14 en | Installation
FLEXIDOME IP starlight
7000 VR
2016.06 | v1.0 | AM18-Q0710 Bosch Security Systems
