Mount inner and outer dome
When the camera position is set and all adjustments have been
made, disconnect the service cable from the video jack.
To attach the inner and outer dome:
1. Place the desiccant sachet inside the inner dome to prevent
damp.
2. Align the inner dome fin with the slot in the camera frame,
and gently click the inner dome into place in its mount seal
3. Check that the lens can move freely in the dome opening.
4. Mount the outer dome by screwing in the 3 attachment
bolts.
5.7
FLEXIDOME IP starlight
7000 VR
Installation | en 25
Bosch Security Systems 2016.06 | v1.0 | AM18-Q0710
