Bosch PC600 - Specifications

Flexible Automation
Digital input modules
1-31070 072 144-101
Specifications
Order no. 1070 ... ...
046 267 046 427 071 252 047 961 075 324 047 963 075 330 044 312
Designation E 220 V E 115 V E 24 V- E 24 V- E 24 V- SF E 24 V- E 24 V- SF E 24 V-
Inputs 16 95 32 16
2pin yes no yes
Input voltage 220 V 115 V 24 V-
Frequency range 48 Hz to 63 Hz
Voltage range 0 0 to 65 V 0 to 35 V -3 V to +6 V
Voltage range 1 175 to 255 V 88 to 133 V +15 to +30 V
Input delay 0  1 5 ms settable 3 ms
Input delay 1  0 25 ms 30 ms settable 3 ms
Input current 5.5 mA 6 mA 4 mA 15 mA
Power input from
12 V intern.
0.5 mA per input set
Simultaneity 100%
Fan unit required yes no
Width 1 division
Fig. 1-1 Input modules, specifications
