Bosch PC600 - Digital Output Modules

Flexible Automation
Digital output modules
2-1
1070 072 144 -101
2 Digital output modules
CAUTION 2.1
Danger to the module!
Do not insert or remove the module when the control is switched on!
This can destroy the module. Switch off or remove the power supply
module of the control, external power supply and signal voltage before
inserting or removing the module!
CAUTION 2.2
Danger to the module!
All ESD protection measures must be observed when using the
module! Avoid electrostatic discharges!
Configuration
Output modules with 8, 16 and 32 outputs are available for selection.
The output drivers are galvanically isolated from the internal logic by using
optocouplers and protected against overloading by fusible cutouts or elec
tronic fuses.
Every output is allocated an LED for indicating the signal status.
D LED lit : 1
D LED not lit : 0
Output module with increased interference immunity
The following output modules are available for operations in environments
particularly vulnerable to interference.
D A 24/0.5- SF, 16 outputs, order no. 1070 075 333
D A 24/16- SF, 16 outputs, order no. 1070 075 337
D AR/2A SF, 16 outputs, order no. 1070 075 340
These output modules meet or exceed the following norms when con
nected according to procedures:
D IEC 2554
D IEC 8012
D IEC 8014
D IEC 1131
D IEC 11312
D EN 602041
D VDE 0160
