Flexible Automation
Digital input modules
1-5
1070 072 144 -101
Expansion
unit EG2
Basic unit
GG2
12345678910111213141234567891011121314
Slots CL400
Expansion
unit EG2/K
12345678
Basic unit
GG2/K
12345678
Fig. 1-4 Input modules, slots CL400
Expansion
unit EG2
Basic unit
GG2
12345678910111213141234567891011121314
Slots CL500
Expansion
unit EG2/K
12345678
Basic unit
GG2/K
12345678
Fig. 1-5 Input modules, slots CL500
