Flexible Automation
Digital output modules
2-24
1070 072 144-101
The output module can be driven with 230 V or 115 V. The output module
has two isolated circles, each with 4 outputs. The circuits may have a po
tential difference of no more than 500 V.
The voltage for each circuit can be set with a switch.
L Switch off power supply module of the control and external power supply.
DANGER 2.20
Lethal voltage!
A lethal voltage exists at the terminals of the module!
Cut off the power supply before working on the module!
CAUTION 2.21
Danger to the module!
Do not insert or remove the module when the control is switched on!
This can destroy the module. Switch off or remove the power supply
module of the control, external power supply and signal voltage before
inserting or removing the module!
L Remove plugin terminals.
CAUTION 2.22
Danger to the module!
All ESD protection measures must be observed when using the
module! Avoid electrostatic discharges!
L Unscrew knurled screws and pull out output module from the subrack.
L Remove insulation covering of the module on the component side, climb
ing cover.
