Bosch Rexroth A10VG - Below-Reservoir Installation (Standard)

32/64 Installation
Bosch Rexroth AG, Series 10 A10VG, RE 92750-01-B/06.2018
7.3.1 Below-reservoir installation (standard)
Below-reservoir installation means that the axial piston unit is installed outside of
the reservoir and below the min. fluid level of the reservoir.
Recommended installation position: 1 and 2.
1 32
4 65
T
1
T
2
S
R
SB
h
t min
h
min
X
1
, X
2
SB
h
t min
h
min
T
2
S
X
1
, X
2
T
2
S
SB
h
t min
h
min
X
1
, X
2
T
2
S
SB
h
t min
h
min
R
X
1
, X
2
T
1
S
SB
h
t min
h
min
X
1
X
2
S
T
2
X
2
SB
h
t min
h
min
X
1
Fig. 8: Below-reservoir installation with installation position 1-6
T
1
, T
2
Highest drain port h
t min
Min. required immersion depth
(200mm)
R Air bleed port h
min
Minimum required distance to
reservoir bottom (100mm)
S Suction port SB Baffle (baffle plate)
X
1
, X
2
Control pressure port
Table 8: Below-reservoir installation
Installation position Air bleeding
the housing
Air bleeding
the stroking
chamber
Filling
Drive shaft Stroking
chamber
1 Horizontal Above R X
1
+ X
2
S + T
1
+ X
1
+ X
2
2 Horizontal Below – – S + T
2
+ X
1
+ X
2
3 Below Horizontal – X
1
+ X
2
S + T
2
+ X
1
+ X
2
4 Above Horizontal R – S + T
2
+ X
1
+ X
2
5 Horizontal Vertical – X
1
S + T
1
+ X
1
+ X
2
6 Horizontal Vertical – X
2
S + T
2
+ X
1
+ X
2
