About this documentation 7/64
RE 92750-01-B/06.2018, A10VG, Series 10, Bosch Rexroth AG
1.3.2 Symbols
The following symbols indicate information that is not safety-relevant but increases
understanding of the documentation.
Table 3: Meaning of symbols
Symbol Meaning
If this information is disregarded, the product cannot be used and/or
operated to its full extent.
▶
Single, independent action
1.
2.
3.
Numbered instruction:
The numbers indicate that the actions must be completed in order.
1.3.3 Designations
This documentation uses the following designations:
Table 4: Designations
Designation Meaning
A10VG Axial piston variable pump, closed circuit
Threaded plug Metal screw, pressure-resistant
Protective plug Made out of plastic, not pressure-resistant, only for transportation
As umbrella term for “axial piston variable pump A10VG” the designation
“axial piston unit” will be used in the following.
