Bosch Rexroth A10VG - Above-Reservoir Installation

Installation 33/64
RE 92750-01-B/06.2018, A10VG, Series 10, Bosch Rexroth AG
7.3.2 Above-reservoir installation
Above-reservoir installation means that the axial piston unit is installed above the
min. fluid level of the reservoir.
Observe the maximum permissible suction heighth
Smax
= 800mm.
The permissible suction heighth
S
is derived from the total pressure loss.
Recommendation for installation position10 (drive shaft upward): A check valve
in the drain line (cracking pressure 0.5bar) can prevent the housing area from
draining.
7 98
10 11 12
T
2
F
2
S
R
SB
h
t min
h
min
h
S
max
F
1
X
1
,
X
2
T
1
T
2
T
1
S
F
2
h
t min
h
min
F
1
h
S max
SB
X
1
,
X
2
T
2
T
1
S
F
2
SB
h
t min
h
min
h
S max
F
1
X
1
,
X
2
T
2
S
R
F
2
SB
h
t min
h
min
0.5 bar
h
S max
F
1
X
1
,
X
2
X
1
T
1
X
2
S
F
2
SB
h
t min
h
min
h
S max
F
1
X
2
SF
2
SB
h
t min
h
min
h
S max
F
1
T
2
X
1
Fig. 9: Above-reservoir installation with installation position 7-12
T
1
, T
2
Highest drain port h
t min
Min. required immersion depth
(200mm)
F
1
, F
2
Filling/air bleeding h
min
Minimum required distance to
reservoir bottom (100mm)
R Air bleed port h
S max
Permissible suction height (800mm)
S Suction port SB Baffle (baffle plate)
X
1
, X
2
Control pressure port
Ports F
1
and F
2
are part of the external piping and must be provided on the
customer side to make filling and air bleeding easier.
