64/108 Bosch Rexroth AG CS351 | 3609929B45/2014-09
Product description
Device description
Fig. 1: Compact System view
Legend relating to Fig. 1:
1 Name plate
2 Front cover lock
3 Cable duct strip
4 Side cable ducts
5 Affixed pressure compensation memb-
rane
(do not remove)
6 Safety warning (only visible when front
cover is open)
7 Type label
Warning
This warns about the high electrical volta-
ges in the Compact System during opera-
tion and provides maintenance information
(see “Disassembly and replacement” on
page 101).
3
4
4
2
1
5
6
7
