CS351 | 3609929B45/2014-09 Bosch Rexroth AG 101/108
Disassembly and replacement
ENGLISH
11 Disassembly and re-
placement
The Compact System must be considered
a unit.
As a result, the entire Compact System
must be exchanged if there are any defects
or malfunctions.
For complaints and repairs, please send the
fully assembled Compact System to the
supplier or our customer service workshop
in Murrhardt, Germany. Complaints and re-
pairs cannot be accepted if this procedure
is not followed.
Disassembling
Follow the warnings printed on the label on
the Compact System:
Fig. 42: Label on the Compact System
Proceed as follows to disassemble the
Compact System:
1. Switch off the power supply to the
Compact System and allow for a
discharging time of at least 90 seconds.
2. Remove the power supply connection
cable.
3. Remove the hand-held nutrunner/tighte-
ning spindle:
4. Release and open the front cover.
5. Disconnect the motor OFF equipment
and external peripherals.
6. After you have removed the module,
close off the module slot with a dummy
panel.
7. Close the front cover.
WARNING
Dangerous internal voltage!
Before opening the device or perfor-
ming maintenance work, make sure
that the device is de-energized, pro-
tect it from being switched on again,
and allow a 90 second discharging
time.
Read the manual before using the
system or performing maintenance
work.
