CS351 | 3609929B45/2014-09 Bosch Rexroth AG 63/108
Product description
ENGLISH
4 Product description
Performance description
The Compact System combines a servo
amplifier, power supply, display, controller,
and slots for optional interface cards.
The system is a comprehensive solution for
use with ErgoSpin or CC-ErgoSpin hand-
held nutrunners or tightening spindles.
Compact System variants for hand-held nu-
trunners include:
• CS351E-D with LC display.
• CS351E-D IL with LC display and inte-
grated logic compliant with IEC 61131-3.
• CS351E-G with large color TFT display
(VGA 640x480) with integrated touch-
screen.
• CS351E-G IL with large color TFT dis-
play (VGA 640x480) with integrated
touchscreen and integrated logic compli-
ant with IEC 61131-3.
• CS351E-G+ with large color TFT display
(VGA 640x480) with integrated touch-
screen, integrated logic compliant with
IEC 61131-3., and integrated computer
unit
• CS351E-D NK with LC display for con-
nection to the modular system 350
(SB356, BT356).
A Compact System variant for hand-held
nutrunners is:
• CC-CS351E-D with LC display.
Compact System variants for tightening
spindles include:
• CS351S-D with LC display.
• CS351S-D IL with LC display and inte-
grated logic compliant with IEC 61131-3.
• CS351S-G with large color TFT display
(VGA 640x480) with integrated touch-
screen.
• CS351S-G IL with large color TFT dis-
play (VGA 640x480) with integrated
touchscreen and integrated logic compli-
ant with IEC 61131-3.
• CS351S-G+ with large color TFT display
(VGA 640x480) with integrated touch-
screen, integrated logic compliant with
IEC 61131-3., and integrated computer
unit
• CS351S-D NK with LC display for con-
nection to the modular system 350
(SB356, BT356)
In normal operating state, the front panel is
covered.
The front cover can be opened or removed
to connect external devices.
