78/108 Bosch Rexroth AG CS351 | 3609929B45/2014-09
Product description
TMSD = transition minimized differential signaling
Tab.12: DVI interface (XDVI) assignment
Pin Signal Description/ function Voltage/ current
1 TMDS data 2– Data 2– DVI differential
2 TMDS data 2+ Data 2+ DVI differential
3 TMDS data 2 shield Shield for data 2 PE potential
4n.c.
5n.c.
6DDC CLK DDC clock
7 DDC data DDC data
8 n.c. Analog Vsync
9 TMDS data 1– Data 1– DVI differential
10 TMDS data 1+ Data 1+ DVI differential
11 TMDS data 1 shield Shield for data 1 PE potential
12 n.c.
13 n.c.
14 VCC 5 V supply 5 V= / 0.5 A
15 GND Reference potential for all volt-
ages
PE potential
16 HPD Hot plug detect
17 TMDS data 0– Data 0– DVI differential
18 TMDS data 0+ Data 0+ DVI differential
19 TMDS data 0 shield Shield for data 0 PE potential
20 n.c.
21 n.c.
22 TMDS clock shield TMDS clock shield PE potential
23 TMDS CLK+ TMDS clock+ DVI differential
24 TMDS CLK– TMDS clock– DVI differential
C1 n.c.
C2 n.c.
C3 n.c.
C4 n.c.
C5 n.c.
