ctrlX CORE
Battery change
Bosch Rexroth AG
R911405645, Edition 02
We may charge you a fee (up to max. 20,- €) to cover the cost of the source code provision.
You may send your request (i) within three (3) years from the date you received the product that
includes the binary file that is subject of your request or (ii) in case of code licensed under the GPL v3
for as long as Bosch Rexroth offers spare parts or customer support for that product.
13 Error causes and troubleshooting
Table 15: Error causes and troubleshooting XF 10
Error Troubleshooting actions
The engineering PC cannot reach the
control via the Ethernet interface “XF10”
• Check whether the device driver was correctly installed
in the “Device manager” of the system control.
•
Check whether the operating system assigned a valid IP
address and a subnet mask to the network adapter (e.g.
via the command “ipconfig”). If this is not the case, con-
figure the IP address and the subnet mask manually.
The customer may not repair the device. Exceptions are maintenance works listed in the
chapter “Maintenance”.
For further information in the event of repair, please contact the Bosch Rexroth Service.
14 Maintenance
NOTICE
Maintenance work in the device is only permitted by trained
staff!
If hardware or software components have to be exchanged,
please contact the Bosch Rexroth Service or ensure that only
skilled staff changes the respective components.
14.1 Scheduled maintenance tasks
Include the following tasks into the maintenance schedule:
• Check all plug and terminal connections of the components for proper tightness and possible
damage at least once a year
•
Ensure that cables are not broken or crushed
•
Replace damaged parts immediately
14.2 Battery change
It is recommended to change the battery of the control ctrlX CORE every three years.
The battery holder GB01 is located on the bottom side of the control. Insert a common CR1025 lithium
battery into a drawer of this battery holder. The design of the battery drawer ensures that inserting the
battery is reverse polarity-protected. In order not to loose the time when changing the battery, a capac-
itor buffers the time for approximately 60 minutes.
Battery name: Lithium battery 3.0 V CR1025 (32 mAH).
