Product information 31/128
CytroBox, RE 51057-B/11.19, Bosch Rexroth AG
Sensor 6.620 at port 6 of the IO link gateway is used to detect the fluid.
If the sensor is not present, the value -999 is output. If the sensor measures an
invalid value, -999 is output as well and warning B328 is issued.
The value of the detected fluid is output in P-0-1274.
Table 11: Parameters for fluid detection
Function Parameter Description Unit Bytes Decimal
points
Default
Fluid detection
P-0-1274 Actual value % 4 1 -
Threshold value
P-0-1389[12] Switch-on threshold % 4 3 -
P-0-1389[41] Debouncing time ms 4 3 -
P-0-1389[42]
Warning
Oil
% 4 3 8
P-0-1389[43]
Warning
Mixture
% 4 3 25
P-0-1389[44]
Warning
Water
% 4 3 70
Table 12: Sensors
Sensors Standard (included in the
scope of delivery)
Optional
Pressure sensor X
Filling level sensor X
Temperature sensor X
Pressure filter contamination sensor X
Leakage flow sensor X
Leakage temperature sensor X
Water content sensor X
Air inclusion sensor X
Dirt particle sensor X
Drip pan leakage sensor X
Fluid detection
