Product information 39/128
CytroBox, RE 51057-B/11.19, Bosch Rexroth AG
Table 33: Overview of "Drainage" parameters
Parameter Description Unit Default
P-0-1272 Actual value % -
P-0-1389[15] Debouncing time ms 
P-0-1389[12] Threshold value % 180
P-0-1389[17] Drainage time sec 15
P-0-1389[22] Degassing time sec 30
P-0-1389[16] Pause time sec 600
Table 34: Parameter P-0-1418
P-0-1418
Description
Degassing valve P-0-1418 Bit 0
Disabled Valve for degassing closed
Enabled Valve for degassing open
Drain valve P-0-1418 Bit 1
Not activated Valve for drainage closed
Activated Valve for drainage open
The monitoring of the system pressure becomes active when the pressure falls
below the threshold value for a debouncing time.
The monitoring of the oil temperature becomes active when the pressure exceeds
the threshold value for a debouncing time.
In both cases, a warning is issued.
5.3.7 RGB LED as status display
The LED is located in the upper door of the CytroBox. The color cyan means OK,
yellow means warning and red means error. The LED is inactive in service mode.
Table 35: Color assignment
LED color Description
Red Drive error
Yellow Drive warning
Cyan
Nothing amiss –
neither error nor warning
5.3.8 Description of parameters and diagnosis
The following chapter includes a list of all available parameters as well as all
occurring errors and warnings.
Monitoring of system
pressure and
oil temperature
