96/128 Commissioning
Bosch Rexroth AG, CytroBox, RE 51057-B/11.19
5. Loading the HPU project (in case of service or update)
To work with the HPU dialog, the software/parameter file must be loaded on the
micro SD card, see Fig. 7, pos.17 on page50.
On delivery, the software/parameter file
FWS-MLDSYX-IMC-02Vxx-D0-MP20-HPU02Vxx-NN is already loaded.
No PLC programming knowledge is required since the CytroBox function is fully
operable via the dialogs and functions in IndraWorks.
To this end, the following steps must be carried out:
1. To display the active MLD program and its status, click "Project info" under the
MLD node in IndraWorks.
2. Here, the loaded software/parameter file can be verified, and it can be ensured
that the program is running ("RUN" status).
3. If necessary, a new program can be loaded (as software/parameter file)
via"Loadproject...".
4. When the project name (FWS-MLDSYX-IMC-02Vxx-D0-MP20-HPU02Vxx-NN) is
displayed, the "SYTRONIX 7020 (IMC02)" dialog appears in the project tree.
Loading the basic parameters results in loss of HPU functionality and should not
be performed.
To restore the condition as supplied in case of error, the HPU
project (FWS-MLDSYX-IMC-02Vxx-D0-MP20-HPU02Vxx-NN) and the
correspondingstandard parameters must be reloaded.
This is only necessary in case of service or for updates.
8.2 Re-commissioning after longer standstill
For re-commissioning after longer standstill, proceed as follows:
 Check:
– the hydraulic fluid level
– hydraulic components and line systems for tightness
 Switch on components with increased caution.
 Bleed the hydraulic system.
 Observe the information in the operating instructions of the machine/system
manufacturer.
Software/parameter file
(*.par)
