Fig. 37: Operating range of the start dialog
The dialog consists of four operating ranges which are explained below:
1. I/O configuration:
Configuration of the input and output signals for the IndraDrive
2. IMC controller:
Configuration of the IMC controller
3. Diagnosis:
Status display and issue of warnings and errors
4. Configuration:
Information on the settings of the overall system (hardware and software)
These four functions can be displayed with the IndraWorks.
