8.1.8 Commissioning of the "electronics"
1. Connection establishment to the CytroBox (IndraDrive)
For commissioning and diagnosis of IndraDrive drives, IndraWorks software is
being used.
• The following components and prerequisites are required for an
Ethernetcommunication with the drive controller:
• Standard Ethernet cable
• Free Ethernet connection on PC or notebook
• IndraWorks DS
IndraWorks DS software can be downloaded for free at
https://www.boschrexroth.com/indraworks - Download .
To configure the drive in IndraWorks, a connection to the drive controller must first
be established. It can be established via an Ethernet connection using a free
Ethernet interface on the drive.
The engineering port X26 on the control section with IP address 192.168.1.10 is
provided for this purpose (see Fig. 7, pos.15 on page50).
The connection can be established directly when IndraWorks DS is started, or via
the menu Extras Connection Connection selection.
The IP address can be changed via the operating unit of the drive controller or via
IndraWorks DS.
If the control system is connected to the company network, follow the
instructions of your network administrator.
Ethernet connection
After starting IndraWorks, the connection selection dialog opens. Select the
networksearch tab to find all devices which are in the same network, regardless of
their IP and computer configuration. You will also find devices with IP configurations
beyond the sub-network used.
However, this requires a fixed IP address set on the PC or notebook (no DHCP).
A search across network boundaries (router) is not possible.
General information
Prerequisites
Establish the connection
