Product information 33/128
CytroBox, RE 51057-B/11.19, Bosch Rexroth AG
The oil level monitoring is always active because the I/O link sensor is available as a
standard. The monitoring is based on a cycle time of 200ms.
Table 16: Oil level monitoring
Message Threshold value
[l]
Debouncing
time [ms]
Diagnostic
number
Bit in status word
(P-0-1412/P-0-1413)
Warning too low P-0-1389[71]
P-0-1389[75]
B301
1
Error too low P-0-1389[73] D301
Warning too high P-0-1389[72] B300
0
Error too high P-0-1389[74] D300
The oil temperature monitoring is always active because the I/O link sensor is
available as a standard. The monitoring is based on a cycle time of 200ms.
Table 17: Oil temperature monitoring
Message Threshold value
[°C]
Debouncing
time [ms]
Diagnostic
number
Bit in status word
(P-0-1412/P-0-1413)
Warning too low P-0-1389[25]
P-0-1389[24]
B308
8
Error too low P-0-1389[27] D308
Warning too high P-0-1389[26] B307
7
Error too high P-0-1389[28] D307
The monitoring of the particle concentration is active if a measured value via
an I/O link sensor is present. The sensor serially reads in the particle concentration
for different particle sizes as ordinal number. The monitoring interval is therefore
specified by the sensor and is 21s in the default configuration.
Table 18: Particle concentration monitoring
Message Threshold value
[OZ]
Debouncing
time [ms]
Diagnostic
number
Bit in status word
(P-0-1412/P-0-1413)
Warning S - 4 µm P-0-1389[61]
-
B302
2
Error S - 4 µm P-0-1389[65] D302
Warning M - 6 µm P-0-1389[62] B303
3
Error M - 6 µm P-0-1389[66] D303
Warning L - 14 µm P-0-1389[63] B304
4
Error L - 14 µm P-0-1389[67] D304
Warning XL - 21 µm P-0-1389[64] B305
5
Error XL - 21 µm P-0-1389[68] D305
Oil level
Oil temperature
Particle concentration
