34/128 Product information
Bosch Rexroth AG, CytroBox, RE 51057-B/11.19
The monitoring of the dissolved air inclusion is active if a measured value via an
I/Olink sensor is present. The monitoring is based on a cycle time of 200ms.
Table 19: Dissolved air inclusion monitoring
Message Threshold value
[mbar]
Debouncing
time [ms]
Diagnostic
number
Bit in status word
(P-0-1412/P-0-1413)
Warning P-0-1389[7]
P-0-1389[9]
B309
9
Error P-0-1389[8] D309
The monitoring of the relative humidity is active if a measured value via an
I/Olinksensor is present. The monitoring is based on a cycle time of 200ms.
Table 20: Relative humidity monitoring
Message Threshold value
[%]
Debouncing
time [ms]
Diagnostic
number
Bit in status word
(P-0-1412/P-0-1413)
Warning P-0-1389[13]
P-0-1389[15]
B310
10
Error P-0-1389[14] D310
The monitoring of the leakage temperature is active if a measured value via an I/O
link sensor is present. The monitoring is based on a cycle time of 200ms.
Table 21: Leakage temperature monitoring
Message Threshold value
[°C]
Debouncing
time [ms]
Diagnostic
number
Bit in status word
(P-0-1412/P-0-1413)
Warning P-0-1389[47]
P-0-1389[46]
B319
12
Error P-0-1389[48] D319
The fluid detection is active if a measured value via an I/O link sensor is present.
Afilling level sensor detects whether fluids are present in the drip pan and whether
it is oil, water or a mixture. The monitoring is based on a cycle time of 200ms.
Table 22: Fluid detection
Message Threshold value
[%]
Debouncing
time [ms]
Diagnostic
number
Bit in status word
(P-0-1412/P-0-1413)
Warning Oil
P-0-1389[42]
P-0-1389[41]
B329
-
Warning Mixture P-0-1389[43] B330
Warning Water P-0-1389[44] B331
Dissolved air inclusion
Relative humidity
Leakage temperature
Fluid detection
