Product information 45/128
CytroBox, RE 51057-B/11.19, Bosch Rexroth AG
S-0-0390 P-0-1300 S-0-0095 Cause Remedy
E2013 B325 B325: error humidity
sensor on port 5
• The water content sensor on
IO link port 5 is no longer
available.
• An error has occurred at the
sensor.
• An incorrect sensor
(vendor/device ID) is
connected to IO link port 5.
 Check the connection and function of
the water content sensor (if the sensor is
no longer needed, reset and restart the
MLDprogram).
 Remove the faulty sensor.
 Check the connection of the humidity sensor
on the basis of the electrical circuit diagram.
E2013 B326 B326: error particle
sensor on port 4
• The dirt particle sensor on
IO link port 4 is no longer
available.
• An error has occurred at the
sensor.
• An incorrect sensor
(vendor/device ID) is
connected to IO link port 4.
 Check the connection and function of the
dirt particle sensor (if the sensor is no longer
needed, reset and restart the MLD program).
 Remove the faulty sensor.
 Check the connection of the particle sensor
on the basis of the electrical circuit diagram.
E2013 B327 B327: return flow filter
clogging very high
The return flow filter monitoring
indicates a warning.
P-0-1283 > P-0-1389[33]
 Check the limit value.
 Check the sensor output signal.
 Replace the return flow filter.
E2013 B328 B328: error liquid
sensor on port 6
• The drip pan leakage sensor
on IO link port 6 is no longer
available.
• An error has occurred at the
sensor.
• An incorrect sensor
(vendor/device ID) is
connected to IO link port 6.
 Check the connection and function of the
drip pan leakage sensor (if the sensor is
no longer needed, reset and restart the
MLDprogram).
 Remove the faulty sensor.
 Check the connection of the drip pan leakage
sensor on the basis of the electrical circuit
diagram.
E2013 B329 B329: oil detected in
drip pan
The leakage monitor in the drip
pan detects oil.
P-0-1274 > P-0-1389[42]
 Check the drip pan.
 Check the oil pipe.
 Check the limit value.
 Check the sensor output signal.
E2013 B330 B330: oil water mix
detected in drip pan
The leakage monitor in the drip
pan detects an oil-water mix.
P-0-1274 > P-0-1389[43]
 Check the drip pan.
 Check the oil and water pipes.
 Check the limit value.
 Check the sensor output signal.
E2013 B331 B331: water detected in
drip pan
The leakage monitor in the drip
pan detects water.
P-0-1274 > P-0-1389[44]
 Check the drip pan.
 Check the water pipes.
 Check the limit value.
 Check the sensor output signal.
E2013 B332 B332: IO link config.
error
• The configuration of the device
description file used for the
IOlink gateway is wrong.
• The device description file
used for the IO link gateway is
wrong.
 Check the configuration of the device
description file used.
 Check the device description itself.
 Use the supplied device description file with
the correct configuration.
