Product information 47/128
CytroBox, RE 51057-B/11.19, Bosch Rexroth AG
S-0-0390 P-0-1300 S-0-0095 Cause Remedy
F2013 D319 D319: temperature of
leakage very high
The monitoring of the leakage
temperature indicates an
alarm.
P-0-1294 > P-0-1389[48]
 Check the limit value.
 Check the sensor output signal.
 Check the oil cooling pump.
 Check the water cooling unit.
 Check the pump and replace it, if necessary.
F2013 D322 D322: fuse -11F4
tripped
The monitoring of the digital
feedback signal of the sensor
supply fuse indicates an alarm.
P-0-1400.2 = P-0-1380.5
 Check fuse -11F4.
 Check the configuration of the signal logic
(NO/NC).
 Check the flashlight.
F2013 D323 D323: error oil level
sensor on port 1
• The oil level sensor on IO link
port 1 is no longer available.
• An error has occurred at the
sensor.
• An incorrect sensor
(vendor/device ID) is
connected to IO link port 1.
 Check the connection and function of the oil
level sensor (if the sensor is no longer needed,
reset and restart the MLD program).
 Remove the faulty sensor.
 Check the connection of the oil level sensor on
the basis of the electrical circuit diagram.
F2013 D327 D327: return flow
filtercontamination
very high
The monitoring of the return
flow filter indicates an alarm.
P-0-1283 > P-0-1389[34]
 Check the limit value.
 Check the sensor output signal.
 Replace the return flow filter.
F2013 D700 D700: user config
input err, P-0-1389 (...)
The configuration of the device
data (e.g. threshold value)
cannot be implemented.
 Check the editable inputs (for details see text).
 Reset the configuration to factory settings.
