Frame size
Motor at‐
tachment
type
Number of mount‐
ing holes
Roughness height of
the screwing surface to
the machine
100 Mounting
feet (4
pcs.)
4 Rz32
130 Foot plates
(2 pcs.)
160 Mounting
feet (4
pcs.)
180 Via stator
profile
225 Mounting
feet (4
pcs.)
Tab. 8-2: Foot assembly
DOK-MOTOR*-IDYN*A*EXPD-IB05-EN-P Bosch Rexroth AG 33/69
Rexroth MAD and MAF Motors in EX px d Design acc. to ATEX Directive 2014/34/EU
Mechanical attachment
