12.11 Motor Control
12.11.1 Expert mode
Code Name Setting range Default Min. Attri.
C1.02 Expert mode
0: Standard mode
1: Expert mode
0 - Stop
0: Every change of a motor parameter leads to a recalculation based on the as-
cending rule.
1: Every motor parameter will stay on it’s value even if a different parameter got
written. So no recalculation based on the ascending rule.
12.11.2 Motor Parameterization
Nameplate parameters configuration
Most of motor data are available on the motor nameplate, based on which the
following parameters of the frequency converter need to be set accordingly.
Code Name Setting range Default Min. Attri.
C1.05 Motor rated power 0.1...1,000.0 kW DOM 0.1 Stop
C1.06 Motor rated voltage 0...480 V DOM 1 Stop
C1.07 Motor rated current 0.01...655.00 A DOM 0.01 Stop
C1.08 Motor rated frequency 5.00...400.00 Hz 50.00 0.01 Stop
C1.09 Motor rated speed 1...60,000 DOM 1 Stop
C1.10 Motor rated power factor
0.00: Automatically identified
0.01...0.99: Power factor setting
0.00 0.00 Stop
If the data for 'Motor rated power factor' C1.10 is not available on the motor
nameplate, keep its default setting '0.00: Automatically identified'. However, the
rotational auto-tuning performance may be affected.
Motor slip frequency configuration
This function is used to compensate the deviation between the motor speed and
the synchronous speed caused by the load. In addition, the mechanical perform-
ance of the motor can be improved with this function.
For V/f control, slip compensation does not work in acceleration, deceleration,
DC-braking processes or regenerative mode.
