15 Technical data
Table 4
General data VM350
Order number 0 608 750 110
Input
Input voltage 200 - 265 V, single or three-phase, 50 - 60 Hz
Input current Depending on the voltage and type of connection,
e.g. 3-phase 230 V: 3 x 7.5 A
nom
3 x 30 A
peak
for 5 s
Output
Intermediate circuit output voltage
Max. intermediate circuit output voltage
200 V
DC
... 325 V
DCnom
... 370 V
DC
420 V
DC Max
Nominal power 3000 VA (at 230 V) 3-phase
1500 VA (at 230 V) single-phase
1000 VA (at 110 V) single-phase
Peak power 10000 VA (at 230 V) for 5 s
Internal supply voltage
VEE
VCC
VDD
24 V 10 A (± 8%)
5.1 V 7 A (± 3%)
–24 V 0.8 A (+20% / –10%)
24 V
ext
external supply voltage (V
EE
at XDN2) 24 V 1 A (± 8%)
Interference suppression EN 55011 class A
Interference immunity DIN EN 61000-4 part 2 to part 5 severity class 4
Permissible ambient temperature 0 to 60 °C with fan
Admissible relative humidity during operation 20 - 90 %, non-condensing
Max. permissible altitude for use 2000 m above sea level (for altitudes more than
2000 m above sea level, we recommend the use of
an isolating transformer)
Operation at altitudes greater than 1000 m
above mean sea level
At more than 1000 m above mean sea level, a reduc-
tion in the nominal power of approx. 1% per 100 m
of altitude may occur due to the reduced air pres-
sure.
Admissible storage temperature –20 °C to 70 °C
Admissible relative storage humidity 20 - 95 %
Protection class Protection class I
Protection type IP20 (protection against accidental contacts) when
installed
Dimensions (W x H x D) 53 mm x 271 mm x 285 mm
Weight 2.8 kg
Switching cycles of emergency OFF circuit approx. 1 million
