User Manual
Bosch Climate 5000 Series Remote Control (06.2022)
5.4.4 SWING
Figure 51
1
Van e
1. Press the SWING button, and the louvers in the indoor unit will oscillate up
and down.
Figure 52
5.4.5 VANE
1. Press the VANE button
2. Continue to press the VANE button to select the specifi c louver to adjust.
("-0" indicates all four louvers are all selected)
3. Press the SWING button to make the selected louvers automatically oscillate
Figure 53
Van e
2
1
Figure 54
To Next Page
