User Manual Bosch Remote Controller for Split Type Ductless Air Conditioner / Heat Pump | 9
Bosch Thermotechnology Corp. | 12.2016
Data subject to change
5 How to use the buttons
5.1 Auto operation
Ensure the unit is plugged in and power is available. The OPERATION indicator on the
display panel of the indoor unit will be fl ashing.
1. Press the MODE button to select AUTO.
2. Press the UP/DOWN button to set the desired temperature. The temperature
can be set within a range of 62°F ~ 86°F in 1°F increments.
3. Press the ON/OFF button to start the air conditioner.
MODE
FA N
TEMP
ON/OFF
SILENCE
F P
TIM
ER
ON
TIMER
OFF
3
1
2
LED F OL LO W
ME
TURB O S EL F
CL EA N
SW ING DIR EC T
SL
EE
P
Figure 5
1. In the Auto mode, the air conditioner can logically choose the mode of
Cooling, Fan, and Heating by sensing the diff erence between the actual
ambient room temperature and the setting temperature on the remote
controller.
2. In the Auto mode, you can not switch the fan speed. The fan speed will
be automatically controlled.
3. If the Auto mode is not comfortable , the desired mode can be
selected manually.
5.2 Cooling /Heating/Fan operation
Ensure the unit is plugged in and power is available. The OPERATION indicator on the
display panel of the indoor unit will be fl ashing.
1. Press the MODE button to select COOL or FAN mode.
2. Press the UP/DOWN buttons to set the desired temperature. In COOL or
HEAT mode, the temperature can be set within a range of 62°F~ 86°F in 1°F
increments.
3. Press the FAN button to select the fan speed in four steps- Auto, Low, Med,or
High.
4. Press the ON/OFF button to start the air conditioner.
MODE
FAN
TEMP
ON/OFF
TIMER
ON
TIMER
OFF
4
1
3
2
SILE NC E
FP
LED F OLLOW
ME
TURB O S ELF
CL EA N
SWIN G D
IR
EC T
SL EE P
Figure 6
In the FAN mode, the setting temperature is not displayed on the remote
controller and you are not able to control the room temperature. In this
case, only step 1, 3 and 4 may be performed.
