19.1 Operating Temperatures and Pressures
Operating Temperatures and Pressures
Cooling Heating
Model
Entering
Water Temp.
(°F)
Water
Flow
(GPM/Ton)
Suction
Pressure
(PSIG)
Discharge
Pressure (PSIG)
Water Temp.
Rise (°F)
Air Temp.
Drop (°F)
Suction
Pressure
(PSIG)
Discharge
Pressure (PSIG)
Water Temp.
Drop (°F)
Air Temp.
Rise
(°F)
RL007
30°
1.4
— — — — 62–72 261–271 5–6 15–19
2
— — — — 64–74 263–273 4–5 15–19
40°
1.4
107–130 155–187 12–18 18–22 76–86 273–283 6–7 17–21
2
107–129 148–177 8–13 18–22 79–89 276–286 4–5 18–22
50°
1.4
108–134 178–218 12–16 17–21 92–102 287–297 8–9 20–24
2
108–132 171–208 8–11 17–22 96–102 290–300 5–6 21–25
60°
1.4
109–137 205–253 11–16 17–21 109–119 302–312 9–10 23–27
2
109–135 198–241 8–11 17–21 114–124 306–316 6–7 24–28
70°
1.4
111–140 235–290 11–14 17–20 127–137 317–327 10–11 26–30
2
110–139 228–278 8–11 18–21 134–144 323–333 7–8 27–31
80°
1.4
111–143 268–330 10–16 17–21 147–157 335–345 12–13 30–34
2
111–142 262–319 7–10 17–21 155–165 342–352 8–9 31–35
90°
1.4
112–146 305–375 10–14 17–20 169–179 354–364 13–14 33–37
2
112–145 300–364 7–10 17–20 — — — —
100°
1.4
114–150 346–423 9–14 16–20 — — — —
2
114–149 343–413 7–10 16–20 — — — —
RL009
30°
1.8
— — — — 61–81 229–285 5–6 18–22
2.4
— — — — 62–83 230–287 4–5 19–23
40°
1.8
107–132 159–191 11–16 20–25 74–97 240–300 6–7 21–26
2.4
107–131 153–183 9–12 20–25 75–100 242–302 4–5 21–26
50°
1.8
109–135 183–223 11–16 20–25 89–116 254–317 7–9 24–30
2.4
109–133 178–215 8–12 20–25 91–120 256–320 5–6 24–30
60°
1.8
111–138 210–257 11–15 19–24 105–136 268–334 8–10 27–34
2.4
111–136 205–250 8–11 20–25 108–141 271–339 6–7 27–34
70°
1.8
111–139 241–295 11–14 19–24 123–157 284–354 9–12 30–38
2.4
112–139 236–288 8–11 19–24 127–164 287–359 7–8 31–39
80°
1.8
113–142 276–338 10–14 19–23 143–181 300–374 10–12 34–42
2.4
114–141 271–330 7–10 19–24 148–168 306–381 8–9 34–43
90°
1.8
116–146 315–384 9–14 18–23 — — — —
2.4
116–145 310–376 8–9 18–23 — — — —
100°
1.8
117–148 357–434 9–12 18–22 — — — —
2.4
118–147 354–427 7–10 18–22 — — — —
