Bosch SSB255 - Page 63

SSB 6720818454 (2016/02) US
Spare parts | 63
Item (→ Fig. 85) Description
SSB255
Order number
1
Flanged exhaust connector ■ 7-738-004-978
2 O-ring anged exhaust connector 6.5x0.23in 165x6mm EPDM ■ 7-738-004-979
3 Heat Exchanger SSB255 ■ 7-738-004-980
4 O-ring burner ange 6.60x0.20in 167.7x5.33mm NBR ■ 7-738-004-983
5 Burner Flange (outer ring) ■ 7-738-004-984
6 Gasket premix burner tube ■ 7-738-004-985
7 Premix burner tube ■ 7-738-004-986
8 Burner Flange (inner ring) ■ 7-738-004-989
9 Gasket burner ange inner ring to fan ■ 7-738-004-990
10 Fan SSB-255 ■ 7-738-005-007
11 Gas valve SSB-255 and washers ■ 7-738-005-009
12 Venturi tube / gas valve washer ■ 7-738-005-011
13 Venturi SSB-255 ■ 7-738-005-013
14 Washer gas pipe 1” 25 mm ■ 7-738-005-014
15 Adapter air intake tube SSB 255 ■ 7-738-005-017
16 Clamp for ex pipe air intake ■ 7-738-005-019
17 Flexible pipe air intake SSB-255 ■ 7-738-005-021
18 Washer gas pipe 3/4” 19.05mm ■ 7-738-005-023
19 Gas pipe SSB-255 ■ 7-738-005-025
22 Frame support gas pipe ■ 7-738-005-029
23 Gas connection 1" ■ 7-738-005-030
24 Sight glass for combustion ■ 7-738-005-031
25 Ignition cable red ■ 7-738-005-032
26 Ignition electrode with washer ■ 7-738-005-033
27 Gasket for ignition electrode ■ 7-738-005-034
30 Circular clamp 1-1/2" - 2-3/8" 40-60mm ■ 7-738-005-015
31 Gasket venturi tube /Fan ■ 7-738-004-950
32 Refractory disc ■ 7-738-005-175
33 Refractory disk retainer ■ 7-738-005-174
34 Male adapter Ø 0.2 inch hose barb x M5 thread ■ 7-738-005-270
35 Balancing tube ■ 7-738-005-269
