Bosch TTCAN - Page 73

User’s Manual
BOSCH
- 73/77 -
Revision 1.6TTCAN
11.11.02
manual_about.fm
In the Message RAM, the first Message Object is reserved for the Reference Message. The
objects 2 to 16 are transmit objects, the objects 17 to 32 are receive objects.
77 24 IF1 Message Data B2 Time_Mark 0320 0320 03F0
78 0E Trigger Memory Access write trigger 7 8007
79 22 IF1 Message Data B1 Type & Msg & Cycle_Code 0100 4406 8000
80 24 IF1 Message Data B2 Time_Mark 03E6 0320 0540
81 0E Trigger Memory Access write trigger 8 8008
82 22 IF1 Message Data B1 Type & Msg & Cycle_Code 8000 0100 A000
83 24 IF1 Message Data B2 Time_Mark 0540 03E6 2200
84 0E Trigger Memory Access write trigger 9 8009
85 22 IF1 Message Data B1 Type & Msg & Cycle_Code 2100 8000 E000
86 24 IF1 Message Data B2 Time_Mark 2000 0540 FFFF
87 0E Trigger Memory Access write trigger 10 800A
88 22 IF1 Message Data B1 Type & Msg & Cycle_Code A000 2100 E000
89 24 IF1 Message Data B2 Time_Mark 2200 2000 FFFF
90 0E Trigger Memory Access write trigger 11 800B
91 22 IF1 Message Data B1 Type & Msg & Cycle_Code E000 A000 E000
92 24 IF1 Message Data B2 Time_Mark FFFF 2200 FFFF
93 0E Trigger Memory Access write trigger 12 800C
94 22 IF1 Message Data B1 Type & Msg & Cycle_Code E000
95 24 IF1 Message Data B2 Time_Mark (EndofList) FFFF
96 0E Trigger Memory Access write trigger 13…32 800D…801F
97 66 TT Clock Control ldSDL=2, CT-TMI, GT-SW 474C
98 28 TT Operation Mode R_T_O, TM, L2, TTMode_3 008B 08CB 7F7B
99 00 CAN Control start operating, enable interrupt 0002
M0 M1 S0
1 Reference Message, Id=0F0…0F7
2 M0_Msg2, Id=302, Tx M1_Msg2, Id=312, Tx S0_Msg2, Id=322, Tx
3 M0_Msg3, Id=303, Tx M1_Msg3, Id=313, Tx S0_Msg3, Id=323, Tx
4 not valid M1_Msg4, Id=314, Tx not valid
5 Tx in Merged_Arb_Win Tx in Merged_Arb_Win Tx in Merged_Arb_Win
6 Tx in Arb_Win2 Tx in Arb_Win2 Tx in Arb_Win2
7 Tx in Arb_Win1 or 3 Tx in Arb_Win1 or 3 Tx in Arb_Win1 or 3
8…16 not valid not valid not valid
17 M1_Msg2, Id=312, Rx M0_Msg3, Id=303, Rx M0_Msg2, Id=302, Rx
18 S0_Msg2, Id=322, Rx S0_Msg3, Id=323, Rx M1_Msg4, Id=314, Rx
19…31 Id=xxx, Rx-FIFO-Start Id=xxx, Rx-FIFO-Start Id=xxx, Rx-FIFO-Start
32 Id=xxx, Rx-FIFO-End Id=xxx, Rx-FIFO-End Id=xxx, Rx-FIFO-End
Line
Ad Register Remark M0 M1 S0
