37 1C IF1 Message Control EoB, DLC=8 (for arb. message) 0088
38 10 IF1 Command Request Arb_Msg1 for message object 5 0005
39 10 IF1 Command Request Arb_Msg2 for message object 6 0006
40 10 IF1 Command Request Arb_Msg3 for message object 7 0007
41 10 IF1 Command Request set objects 8…16 to not valid 0008…0010
42 1A IF1 Arbitration2 MsgVal, Dir=Rx, xx_Msgx id 8C48 8C0C 8C08
43 1C IF1 Message Control EoB, DLC=8 (receive object) 0088
44 10 IF1 Command Request xx_Msgx in message object 17 0011
45 1A IF1 Arbitration2 MsgVal, Dir=Rx, xx_Msgx id 8C88 8C8C 8C50
46 10 IF1 Command Request xx_Msgx in message object 18 0012
47 14 IF1 Mask1
all bits masked except Dir
0000
48 16 IF1 Mask2 4000
49 18 IF1 Arbitration1
MsgVal, Dir=Tx/Rx
0000
50 1A IF1 Arbitration2 A000
51 1C IF1 Message Control UMask, DLC=0, start of FIFO 1000
52 10 IF1 Command Request objects 19…31 are Rx-FIFO 0013…001F
53 1C IF1 Message Control UMask, EoB, end of FIFO 1080
54 10 IF1 Command Request object 32 is end of Rx-FIFO 0020
55 22 IF1 Message Data B1 Type & Msg & Cycle_Code 4202 D203 4303
56 24 IF1 Message Data B2 Time_Mark 00A0 0138 00A0
57 0E Trigger Memory Access write trigger 0 8000
58 22 IF1 Message Data B1 Type & Msg & Cycle_Code D200 4202 D102
59 24 IF1 Message Data B2 Time_Mark 01D8 01E0 0138
60 0E Trigger Memory Access write trigger 1 8001
61 22 IF1 Message Data B1 Type & Msg & Cycle_Code 4303 D103 4200
62 24 IF1 Message Data B2 Time_Mark 01E0 0278 0140
63 0E Trigger Memory Access write trigger 2 8002
64 22 IF1 Message Data B1 Type & Msg & Cycle_Code D102 6504 6504
65 24 IF1 Message Data B2 Time_Mark 0278 0280 0280
66 0E Trigger Memory Access write trigger 3 8003
67 22 IF1 Message Data B1 Type & Msg & Cycle_Code 6504 4303 4606
68 24 IF1 Message Data B2 Time_Mark 0280 0280 0280
69 0E Trigger Memory Access write trigger 4 8004
70 22 IF1 Message Data B1 Type & Msg & Cycle_Code 4606 4606 4504
71 24 IF1 Message Data B2 Time_Mark 0280 0280 0320
72 0E Trigger Memory Access write trigger 5 8005
73 22 IF1 Message Data B1 Type & Msg & Cycle_Code 4504 4504 4703
74 24 IF1 Message Data B2 Time_Mark 0320 0320 0320
75 0E Trigger Memory Access write trigger 6 8006
76 22 IF1 Message Data B1 Type & Msg & Cycle_Code 4703 4703 D206
Line
Ad Register Remark M0 M1 S0
