28 en | Navigating the Monitor Bosch HD LCD Monitors
F.01U.272.027 | 1.0 | 2012.08 User's Manual Bosch Security Systems, Inc.
6.4 Image Menu
To access the Image menu, press the Menu button on the front
panel of the monitor, then press the Up and Down arrow
buttons to select the Image icon. Press the Left arrow button to
enter the menu, and then press the Up and Down arrow
buttons to select a submenu. When finished, press the Menu
button to save any changes, then press the Menu button again
to exit the OSD.
Brightness 000
Contrast 000
Color Temp.
Zoom 4:3
Information Bar On
:Move :Select :Menu
Submenu Definition
Brightness Adjusts the brightness level for video performance (range 0-
100).
Contrast Adjusts the intensity of the image (range 0-100).
Color Temp. Adjusts the color of the picture Choices are Warm, Normal,
Cool, and User (Red, Green, and Blue).
Zoom Sets the aspect ration for the monitor. Choices are 16:9 and
4:3.
Information
Bar
Displays two bars on either side of the image when the
monitor displays an image transmitted in 4:3:
