Table 5 Boiler dimensions
2.9 Operation conditions
Observe the maximum rated heat input Qn (Hi) specified on the data
plate when setting the burner output.
Table 6 Operation conditions
Table 7 Operation conditions
It must be possible to check the number of burner starts, e.g. at the user
interface, third-party control unit, building control system or burner
control unit.
Boiler return (RK1)
2)
Ø RK1 DN 100 125 125
H
RK1
mm 1007 1148 1148
A
5
mm 320 380 380
Boiler return (RK2)
2)
Ø RK2 DN 80 100 100
H
RK2
mm 300 263 263
A
6
mm 320 390 390
Pressure relief valve/flow safety pipe
3)
Ø VSLP DN 65 65 65
A
3
mm 400 400 400
Boiler safety assembly connection Ø AAB inch G1 G1 G1
A
1
mm 1200 1245 1245
Condensate discharge Ø AKO DN 40 40 40
H
AKO
mm 180 180 180
A
7
mm 71 70 70
Drain Ø EL inch R1 R1 R1
H
EL
mm 161 164 164
Fitting clearance (width) B mm 960 1040 1040
Fitting clearance height
1)
H
EB
mm 1874 2052 2052
Delivery length
4)
– mm 2405 2455 2455
1) The transport height can be reduced by removing the base frame rails.
2) Acc. to EN 1092-1 PN 6.
3) Acc. to EN 1092-1 PN 16.
4) Following disassembly of burner door
Abbreviation Unit Boiler type
800 1000 1200
Operation conditions Unit Value
Maximal permissible temperature of
high limit safety cut-out /(STB)
°C 110
Maximum operating pressure bar Dependent on boiler
size
Maximum number of burner starts per
annum
15 000
Operation conditions Uni Condens 8000 F
800...1200 with
modulating
operation
Uni Condens 8000 F
800...1200 with
constant boiler
temperature
Volumetric flow rate None –
In conjunction with a
CFB/CC control unit
for modulating
operation (CFB 840;
CFB 810; CFB 830 or
CC 8311; CC 8312).
None
In conjunction with a
CFB/CC control unit
for constant boiler
temperature CFB 810
or CC 8312, or when
supplemented by a
third party control
unit.
Min. boiler water
temperature
Operating Interruption
(complete boiler shut-
down)
Heating circuit control
unit with heating mixer
Minimum return
temperature
Miscellaneous
1)2)
1) Maximum 15,000 burner starts per year. In order not to exceed the number of
burner starts, observe the information on setting the control unit and burner in
the technical guide or installation instructions. If this value is still however
exceeded, please contact the customer service of the manufacturer.
2) The number of burner starts per year is influenced by the boiler system's
operating settings (control parameters in the boiler control and the combustion
setting) and by the design of the boiler system with regard to the consumer's
heat requirement. To avoid exceeding the number of burner starts per year as a
result of operating settings that have not been optimised, the manufacturer
offers complete commissioning and regular system inspections for boilers,
burners and boiler controls (CFB/CC controllers with function modules).
1)
