2.8 Connections and dimensions
You can find additional technical data in chapter 14.1, page 41.
Fig. 2 Connections and dimensions
Abbreviation Unit Boiler type
800 1000 1200
Boiler size – kW 800 1000 1200
Length L mm 2545 2580 2580
L
K
mm 2360 2395 2395
Length incl. burner L
BR
mm Subject to burner
Width B mm 960 1040 1040
Width incl. control unit B
RG
mm 1220 1330 1330
Height H
K
mm 2014 2192 2192
Height of base frame
1)
H
GR
mm 140 140 140
Installation clearance control unit, cable
conduit
L
RG
mm 906 906 906
Installation height, control unit right/left H
RG
mm 1300 1300 1300
Installation surface base frame L
GR
mm 2060 2060 2060
B
GR
mm 960 1040 1040
Flue gas outlet Ø D
AAinside
mm 253 303 303
H
AA
mm 1064 1193 1193
A
4
mm 299 348 348
Combustion chamber Length mm 1904 1954 1954
Ø
internal
mm 630 688 688
Burner door L
BT
mm 227 227 227
H
BT
mm 1508 1653 1653
Blast tube Minimum depth mm 210 210 210
Boiler flow
2)
Ø VK DN 100 125 125
A
2
mm 403 405 405
0010014758-001
B
GR
H
AKO
A
7
H
EB
H
K
H
GR
H
BT
AKO
B
RG
H
AA
ØD
AAi
A
4
A
5
A
6
RK1
RK2
H
RK1
H
RG
H
RK2
VSL
VK
AAB
L
A
12
A
3
L
BT
A
EL
H
EL
L
GR
L
K
B
L
RG
