Clear rugged
polycarbonate
VGA-BUBBLE-PCLR
Tinted rugged
polycarbonate
VGA-BUBBLE-PTIR
Replacing an In-ceiling Rugged
Polycarbonate Bubble
Notice!
The following instructions are for bubbles VGA-BUBBLE-CCLR
and VGA-BUBBLE-CTIR (on AUTODOME models VG4, VG5-1xx,
and VG5-6xx).
1. Loosen the lockscrew (item 1, below) in the trim ring using
a P1 or smaller Phillips screwdriver until the bubble can
rotate freely.
2. Then rotate the bubble counterclockwise approximately 1/4
turn until it releases from the in-ceiling housing.
Notice!
For VGA-BUBBLE-CCLR and VGA-BUBBLE-CTIR, you must reuse
the rings that came with the bubble that you are replacing.
Continue with steps 3 through 8.
3.1
AUTODOME Bubble
Replacement (VG4, VG5,
or 7000 Series)
Replacing an AUTODOME Bubble | en 13
Bosch Security Systems, Inc. 2013.06 | 2.1 | F.01U.288.194
