10 Technical data
Electrical / PSU
Power supply Wide-range, external, included in the box
Input voltage 100 to 240VAC
1.2A
50/60Hz ClassI
Output 19VDC
3.16A
Efficiency Energy Star EPS2.0/ ErP Lot 7
Energy Efficiency DOE Level VI
Electrical / System
Input 19VDC
3.16A
Video
Video outputs 2 simultaneously
– connector 1x HDMI 2.0a
1x DisplayPort 1.2 (via USB-C)
Standards H.265 / HEVC (ISO/IEC 23008-2)
H.264 (ISO/IEC 14496-10)
MPEG‑4
Data rates
– MP up to 32Mbps
– 4KUHD up to 32Mbps
– HD up to 20Mbps
– SD up to 6Mbps per stream
GOP structure I, IP, IBBP
Monitor resolutions 1920x1280 (HD) at 60Hz
3840x2160 (UHD) at 30Hz
Audio
G.711
– Frequency range 300Hz to 3.4kHz
– Data rate 80kbps at 8kHz sampling rate
L16 (reception only)
– Frequency range 300Hz to 6.4kHz
– Data rate 640kbps at 16kHz sampling rate
AAC-LC
