Description
The cutting gap between the top and bottom blades normally amounts to 0.003 inches
(0.08mm). For the Lite model, the gap should be 0.002 inches (0.05mm).
New adjustment off the cutting gap is done as follows:
1. Adjust main switch to 0 position (OFF).
2. Place bottom blades into the table and align them with the rear stop area. Tighten cylinder
screws slightly.
3. Tighten top blades firmly to ram.
4. Adjust main switch to 1 (ON).
5. Adjust PROG button to set-up.
6. Tap on DOWN button until the lowest position has been reached.
7. Adjust main switch to 0 position (OFF).
8. Adjust the desired cutting gap using a gauge, i.e. by moving the bottom blades against the
top blades.
9. Tighten screws firmly.
10. Adjust main switch to 1 (ON).
11. Move ram upwards by pressing the UP button.
4.4 Adjustment of cutting gap
4.5 Adjustment of stroke
See section 12.12, page 60
