12.12 Stroke adjustment Boschert Lite, Eagle and Silver Eagle
Spare Parts
To lengthen or shorten the downward stroke of the cutting blades below the table
surface:
1. Loosen set screw on lower locking nut.
2. To lengthen stroke, move knurled nut and locking nut upwards; to shorten stroke, move
knurled nut and locking nut downwards.
3. Tighted set screw at desired position.
To raise or lower the upper limit of the cutting blades:
1. Loosen set screw on upper locking nut.
2. To raise the upper stroke limit, move knurled nut and locking nut downwards; to lower the
limit, move knurled nut and locking nut upwards.
3. Tighten set screw at desired position.
