Bose 437308 - Amplifier Ports

26
|
ENG
AMPLIFIER PORTS
PORT DESCRIPTION
POWER
Applies power when the AC power cord is inserted into the port and
then plugged into an AC (mains) outlet (see page 19).
Enables you to connect the Main amplifier to your network or to
connect multiple Main amplifiers together using an Ethernet cable (not
provided). See page 24.
LINE OUT
LINE IN
Enables you to connect a Supplemental amplifier or an external source
using a RCA audio cable (not provided). See page 61.
BASS
Enables you to connect a Bose Bass Module using a 3.5 mm stereo
audio cable (not provided). See page 40.
OPTICAL IN
Enables you to play digital audio from an external source using an
optical cable (not provided). See page 61.
SERVICE USB Type-C® port for service.
SPEAKERS OUT Enables you to connect up to two pairs of speakers (see page 18).
