APPENDIX B: WALL MOUNTING
2. Mark the four mounting hole locations on the wall through the mounting
bracket holes.
RACK MOUNT
FRONT
WALL MOUNT
UP
3. Remove the mounting bracket.
4. Drill four holes in the wall.
• If mounting on wood, drill
33
⁄3232" holes, then continue with step 5.
• If mounting on wallboard or masonry, refer to the instructions provided with the
anchors for the proper hole size and instructions for mounting the bracket to
the wall.
5. Align the mounting bracket to the drilled holes.
