ELECTRICAL PART LIST
Resistors
ESP-88 Chassis Motherboard PCB Assembly
Reference
Designator
Description Vendor Vendor Part Number Note
JP200 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4
JP201 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4
JP202 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4
JP203 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4
R100 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R101 1K, 0603, 1/10W, 1% Yageo RC0603FR-071K 4
R102 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4
R103 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4
R104 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4
R105 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4
R200 220K, 0603, 1/10W, 1% Yageo RC0603FR-07220K 4
R201 8.2K, 0603, 1/10W, 1% Yageo RC0603FR-078K2 4
R202 12K, 0603, 1/10W, 1% Yageo RC0603FR-0712K 4
R204 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R205 2.2K, 0603, 1/10W, 1% Yageo RC0603FR-072K2 4
R208 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4
R209 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4
R210 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00 4
R211 1K, 0603, 1/10W, 1% Yageo RC0603FR-071K 4
R213 1K, 0603, 1/10W, 1% Yageo RC0603FR-071K 4
R214 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R215 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R216 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R220 2.2K, 0603, 1/10W, 1% Yageo RC0603FR-072K2 4
R221 2.2K, 0603, 1/10W, 1% Yageo RC0603FR-072K2 4
R236 220K, 0603, 1/10W, 1% Yageo RC0603FR-07220K 4
R238 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R239 2.2K, 0603, 1/10W, 1% Yageo RC0603FR-072K2 4
R240 8.2K, 0603, 1/10W, 1% Yageo RC0603FR-078K2 4
R241 12K, 0603, 1/10W, 1% Yageo RC0603FR-0712K 4
R300 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R301 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R302 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R303 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R304 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R305 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R306 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R307 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R308 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R309 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R310 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R311 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R312 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R313 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R314 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R315 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
R316 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R 4
