Bose ControlSpace ESP-88 - Zone Controller

63
ELECTRICAL PART LIST
CC-16 Zone Controller
Resistors
Capacitors
Reference
Designator
Description Vendor Name Vendor Part
Number
Note
R1 715 OHM, 0603, 1/10W, 1% Yageo Corporation RC0603FR-07715R 4
R2 240 OHM, 0603, 1/10W, 1% Yageo Corporation RC0603FR-07240R 4
R3 100K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-07100K 4
R4 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K 4
R5 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K 4
R8 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K 4
R6 120 OHM, 1206, 1/4W, 5% Yageo Corporation RC1206JR-07120R 4
R7 1.2K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-071K2 4
R9 1.2K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-071K2 4
R11 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K 4
R12 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K 4
R13 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K 4
R14 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K 4
R15 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K 4
R16 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K 4
R17 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K 4
R18 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K 4
R10 47K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0747K 4
R22 4.7K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-074K7 4
Reference
Designator
Description Vendor Name Vendor Part
Number
Note
C1 47uF, 50V, SMD, ECAP,
+105/-55C, 20%, D6.3x7.7
Nichicon Corp
UUD1H470MCR1GS
4
C2 100uF, 16V, SMD, ECAP,
+105/-55C, 20%, D6.3X5.4
Nichicon Corp
UWT1C101MCR1GB
4
C3 20pF, 0603, 50V, NPO, 5% Teamyoung Corp 0603N200J500BB 4
C4 20pF, 0603, 50V, NPO, 5% Teamyoung Corp 0603N200J500BB 4
C5 220pF, 0603, 50V, NPO, 5% Teamyoung Corp 0603N221J500BB 4
C6 0.1uF, 0603, X7R, 16V, 10% Teamyoung Corp 0603B104K160BB 4
C7 0.1uF, 0603, X7R, 16V, 10% Teamyoung Corp 0603B104K160BB 4
C8 0.1uF, 0603, X7R, 16V, 10% Teamyoung Corp 0603B104K160BB 4
C9 0.1uF, 0603, X7R, 16V, 10% Teamyoung Corp 0603B104K160BB 4
C10 0.1uF, 0603, X7R, 16V, 10% Teamyoung Corp 0603B104K160BB 4
C11 0.1uF, 0603, X7R, 16V, 10% Teamyoung Corp 0603B104K160BB 4
C12 0.1uF, 0603, X7R, 16V, 10% Teamyoung Corp 0603B104K160BB 4
Reference
Designator
Description Vendor Name Vendor Part
Number
Note
- RECT, 400V/1A, SOD-106 Rohm Semi 1SR154-400 4
D1 SCHOTTKY BARR, SOD-80C Philips Semi BAS85 4
D2 SCHOTTKY BARR, SOD-80C Philips Semi BAS85 4
D3 SCHOTTKY BARR, SOD-80C Philips Semi BAS85 4
D4 SCHOTTKY BARR, SOD-80C Philips Semi BAS85 4
Diodes
