22
ELECTRICAL PART LIST
Capacitors
ESP-88 Chassis Motherboard PCB Assembly
Reference
Designator
Description Vendor Vendor Part Number Note
C100 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C101 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C102 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C103 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C104 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C105 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C106 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C107 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C108 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C109 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C110 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C111 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C112 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C113 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C114 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C115 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C116 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C117 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C118 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C119 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C120 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C121 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C122 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C123 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C124 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C125 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C126 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C127 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C200 47uF, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C201 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C202 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C203 47uF, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C204 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C205 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C206 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C207 47uF, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C208 10uF, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C209 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C210 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C211 10uF, 16V, 40C, 20% NICHICON UZT1C100MCR1GB 4
C212 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C220 47uF, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C221 47uF, 16V, 40C, 20% NICHICON UZT1C470MCR1GB 4
C222 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C223 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC 4
C300 47pF, 0603, 50V, 55C, NPO, 5% Samsung CL10C470JBNC 4
