Bose ControlSpace ESP-88 - Page 25

25
ELECTRICAL PART LIST
Diodes
ESP-88 Chassis Motherboard PCB Assembly
Transistors
Integrated Circuits
Reference
Designator
Description Vendor Vendor Part Number Note
D200 400V, 1A, 1SR154-400, SOD-106 ROHM 1SR154-400 4
D201 400V, 1A, 1SR154-400, SOD-106 ROHM 1SR154-400 4
D202 400V, 1A, 1SR154-400, SOD-106 ROHM 1SR154-400 4
D207 400V, 1A, 1SR154-400, SOD-106 ROHM 1SR154-400 4
D208 400V, 1A, 1SR154-400, SOD-106 ROHM 1SR154-400 4
Reference
Designator
Description Vendor Vendor Part Number Note
Q100 PNP, 50V, 100mA, SOT-23 KEC KRA102S 4
Q202 PNP, 60V, 1A, SOT-89 KEC KTA1668Y 4
Q203 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
Q205 NPN, 50V, 100mA, SOT-23 KEC KRC102S 4
Q211 PNP, 50V, 100mA, SOT-23 KEC KRA102S 4
Reference
Designator
Description Vendor Vendor Part Number Note
M100 DECODER, TSSOP-16 ONSEMI MC74VHC138DT 4
M101 OCTAL BUS BUFFER, TSSOP-20 ONSEMI MC74VHC541DT 4
M102 OCTAL BUS BUFFER, TSSOP-20 ONSEMI MC74VHC541DT 4
M103 OCTAL BUS BUFFER, TSSOP-20 ONSEMI MC74VHC541DT 4
M104 DECODER, TSSOP-16 ONSEMI MC74VHC138DT 4
M200 REGULATOR, 3.3V, 1A, TO-252 NEC UPC2933T 4
Reference
Designator
Description Vendor Vendor Part Number Note
CN100 CONN, P1.0MM, 30 PIN, MALE KEL Corp. 87BMN-030S 4
CN101 CONN, P1.0MM, 30 PIN, MALE KEL Corp. 87BMN-030S 4
CN102 CONN, P1.0MM, 30 PIN, MALE KEL Corp. 87BMN-030S 4
CN103 CONN, P1.0MM, 30 PIN, MALE KEL Corp. 87BMN-030S 4
CN104 CONN, P1.0MM, 30 PIN, MALE KEL Corp. 87BMN-030S 4
CN105 CONN, P1.0MM, 30 PIN, MALE KEL Corp. 87BMN-030S 4
CN106 CONN, P1.0MM, 30 PIN, MALE KEL Corp. 87BMN-030S 4
CN107 CONN, P1.0MM, 30 PIN, MALE KEL Corp. 87BMN-030S 4
CN108 CONN, P1.0MM, 100 PIN, MALE KEL Corp. 87BMN-100S 4
CN200 WIRE TO BOARD HEADER,
P3.96MM, 6 POLES, 2114S-06
CompuTime 4024406-----0N19 4
CN202 WIRE TO BOARD HEADER,
P2.5MM, 8 POLES, 2317SJ-08
CompuTime 4024208-----0N19 4
CN203 WIRE TO BOARD HEADER,
P2.5MM, 8 POLES, 2317SJ-08
CompuTime 4024208-----0N19 4
CN205 WIRE TO BOARD HEADER,
P2.5MM, 3 POLES, 2317SJ-03
CompuTime 4024203-----0N19 4
Miscellaneous
