ELECTRICAL PART LIST
Resistors (continued)
ESP-88 Chassis 4x4 PCB Assembly
Reference
Designator
Description Vendor
Name
Vendor Part Number Note
R150 12K, 0603, 1/10W, 1% Yageo RC0603FR-0712K 4
R151 6.8K, 0603, 1/10W, 1% Yageo RC0603FR-076K8 4
R152 6.8K, 0603, 1/10W, 1% Yageo RC0603FR-076K8 4
R153 12K, 0603, 1/10W, 1% Yageo RC0603FR-0712K 4
R156 12K, 0603, 1/10W, 1% Yageo RC0603FR-0712K 4
R157 6.8K, 0603, 1/10W, 1% Yageo RC0603FR-076K8 4
R158 6.8K, 0603, 1/10W, 1% Yageo RC0603FR-076K8 4
R159 12K, 0603, 1/10W, 1% Yageo RC0603FR-0712K 4
R160 12K, 0603, 1/10W, 1% Yageo RC0603FR-0712K 4
R161 6.8K, 0603, 1/10W, 1% Yageo RC0603FR-076K8 4
R162 12K, 0603, 1/10W, 1% Yageo RC0603FR-0712K 4
R163 6.8K, 0603, 1/10W, 1% Yageo RC0603FR-076K8 4
R164 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R165 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R166 39K, 0603, 1/10W, 1% Yageo RC0603FR-0739K 4
R167 39K, 0603, 1/10W, 1% Yageo RC0603FR-0739K 4
R168 39K, 0603, 1/10W, 1% Yageo RC0603FR-0739K 4
R169 4.7K, 0603, 1/10W, 1% Yageo RC0603FR-074K7 4
R170 1.8K, 0603, 1/10W, 1% Yageo RC0603FR-071K8 4
R171 1.2K, 0603, 1/10W, 1% Yageo RC0603FR-071K2 4
R172 4.7K, 0603, 1/10W, 1% Yageo RC0603FR-074K7 4
R173 4.7K, 0603, 1/10W, 1% Yageo RC0603FR-074K7 4
R174 1.8K, 0603, 1/10W, 1% Yageo RC0603FR-071K8 4
R175 1.2K, 0603, 1/10W, 1% Yageo RC0603FR-071K2 4
R176 4.7K, 0603, 1/10W, 1% Yageo RC0603FR-074K7 4
R200 100K, 0603, 1/10W, 1% Yageo RC0603FR-07100K 4
R201 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4
R202 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4
R203 100K, 0603, 1/10W, 1% Yageo RC0603FR-07100K 4
R210 1.3K, 0603, 1/10W, 1% Yageo RC0603FR-071K3 4
R212 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1 4
R215 82 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0782R 4
R217 68 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0768R 4
R220 1.3K, 0603, 1/10W, 1% Yageo RC0603FR-071K3 4
R222 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1 4
R225 82 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0782R 4
R227 68 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0768R 4
R231 680 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07680R 4
R232 680 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07680R 4
R233 680 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07680R 4
R234 680 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07680R 4
R235 680 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07680R 4
R236 680 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07680R 4
R237 680 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07680R 4
R238 680 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07680R 4
R241 39K, 0603, 1/10W, 1% Yageo RC0603FR-0739K 4
R242 39K, 0603, 1/10W, 1% Yageo RC0603FR-0739K 4
